LPT6500E
Diag. Code No. English Description Qty.
1 LSC08038
法兰螺栓M8*38
Flange hd hex. bolt 7
2 16002003
机油尺密封圈
Oil filler cap gasket 2
3 ZC6202
滚珠轴承
Ball bearing 2
4 XA0814
定位销
Sleeve 2
5 34002004
曲轴箱盖垫片
Case cover gasket 1
6 ZC6207
滚珠轴承6207
Ball bearing 1
7 YF355208
LT340/390 油封35*52*8
Oil seal 1
8 34002001
曲轴箱盖
Crankcase cover 1
10 24002002
带刻度机油尺
Oil filler cap 2
11 LSB06012
螺栓M6*12
Flange hd hex. bolt 2
12 34009003
调速弹簧
Governor spring 1
13 16009005
调速臂螺栓M6*21
Governor arm bolt 1
14 LMB6
螺母M6
Flange hd hex. Nut 1
15 34009004
调速臂
Regulating arm 1
16 34009001
调速拉杆
Governor rod 1
17 34009002
节气门复位拉簧
Throttle return spring 1
18 Flange hd hex. bolt 1
19 34009200
调速控制组件
Speed control ass'y 1
20 24001008
调速推盘
Governor 1
21 16001007
调速轴卡簧
Governor shaft cap 1
22 16001004
垫片6
Washer 2
23 24001006
调速轴
Governor shaft 1
24 34001101
调速齿轮组件
Governor weight 3
25 34001102 Governor weight pin 3
26 34001100
调速齿轮组件
Complete governor gear 1
27 ZC6202
滚珠轴承
Ball bearing 1
29 39001001
箱体
Crankcase 1
30 24001011
浸塑线夹
Wire retainer 2
31 LSB06010 Flange hd hex. bolt 1
32 LSB12015
放油螺塞
Drain plug bolt 2
33 24001005
放油螺塞垫片
Drain plug seal 1
34 YF355208
油封35*52*8
Oil seal 1
35 01010
曲轴箱过线套
Wire protector 1
36 ZC6207
滚珠轴承
Ball bearing 1
37 34001002
调速摆杆
Governor arm 1
38 24001003
调速摆杆锁夹
Lock clip 1
39
弹垫
Washer 1
39-2 Washer 2
39-3 YF081405
摆杆油封
Oil seal 1
40 16005204
摇臂轴调节螺母
Pivot adjusting nut 2
41 16005202
摇臂轴座销
Rocker pivot pin 2
42 24005201
气门摇臂
Valve rocker 2
44 24005009
排气门调节帽
Valve rotator 1
45 24005007
进气门弹簧座
Intake valve seat 1
46 24005006
气门弹簧
Valve spring 2
47 24005010
排气门弹簧下座
Spring retainer exhaust valve 1
48 34005004
进气阀
Intake valve 1
49 39005100
凸轮轴总成
Camshaft ass'y 1
50 24005001
气门挺柱
Tappet 2
51 34005002
推杆
Push rod 2
52 24005003
推杆导板
Push rod guide plate 1
53 16005203
摇臂轴螺栓
Pivot bolt 2
54 34005005
排气阀
Exhaust valve 1
55 24005008
排气门弹簧座
Exhaust valve seat 1
56 24004200
火花塞
Spark plug 1
57 LZA08032
单机双头螺柱AM8*32
Threaded stud 2
59 34004100
气缸盖组件
Cylinder head assy 1
60 24004104
气门导管夹
Valve guide clip 1
61 34004101
气缸头
Cylinder head 1
