GROUP INDEX
Group Name Page
GENERATOR ............................................................................................. 6
FRAME ....................................................................................................... 8
CONTROLS .............................................................................................. 10
COVER ..................................................................................................... 12
CRANKCASE GROUP ............................................................................. 14
CRANKSHAFT GROUP ........................................................................... 16
INTAKE and EXHAUST GROUP .............................................................. 18
GOVERNOR GROUP .............................................................................. 20
COOLING and STARTING GROUP ......................................................... 22
FUEL, LUBRICANT GROUP .................................................................... 26
CARBURETOR GROUP .......................................................................... 28
ELECTRIC DEVICE GROUP .................................................................. 30
ACCESSORY GROUP ............................................................................. 32
SYMBOL DESCRIPTION
AY ...........................ASSEMBLY
CP ...........................COMPLETE
EX ...........................EXPORT (from Japan)
FIG. .........................FIGURE
FR. ..........................FRONT
" ..............................INCH
INCL. ......................INCLUDE
~L ............................LITER
L= ...........................LENGTH (in. mm)
L.H. (LH) .................LEFT-HAND SIDE
MECH ..................... MECHANICAL
NO (NON) ...............NONE
OPT.........................OPTIONAL
O.S. ........................OVER SIZE
SYMBOL DESCRIPTION
P= ...........................PITCH (in mm)
P.T.O. (PTO) ...........POWER TAKE OFF
REF. ........................REFERENCE
R.H. (RH) ................RIGHT HAND SIDE
RR. .........................REAR
STD. .......................STANDARD
SW ..........................SWITCH
T= ...........................THICKNESS (in mm)
UN ..........................UNIT
U.S..........................UNDER SIZE
~V ........................... VOLTAGE
~W .......................... WATT
W/ ...........................WITH
W/O ........................WITHOUT
INDEX OF DESCRIPTION SYMBOLS
