Subaru RG2800i 60Hz [11/34] Section 3 control group
![Subaru RG2800iS 60Hz Silent [11/34] Section 3 control group](/views2/1934607/page11/bgb.png)
REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG
R1700i - 11 - 05-04
SECTION 3 CONTROL GROUP
480 014-00501-00 SCREW 4 300
500 33K-40031-50 CONTROL PANEL AY 1
300
505 33K-40101-03 FRONT PANEL 1 300
510 33K-41905-03 FILM 1 300
523 34K-41812-03 ROCKER SWITCH 1 300
528 33K-41813-03 SWITCH COVER 1 300
530 391-47000-03 AC RECEPTACLE 1 300
535 351-49920-08 SCREW and WASHER AY 2 300
537 002-17040-00 NUT 2 300
545 33K-40700-03 CONSENT BRACKET 1 300
547 013-10400-60 SCREW and WASHER AY 4 300
580 KD3-11011-11 OIL and RUN INDICATOR 1 300
583 015-00300-20 TAPPING SCREW 2
300
615 33K-41811-03 MICRO SWITCH 1 300
630 33K-42010-03 CONTROL DIAL 1 300
632 33K-42071-03 BALL, dial 1 300
634 33K-42074-03 SPRING, dial 1 300
636 33K-42020-03 CHOKE REEL 1 300
638 33K-42030-13 PLATE 1 300
640 33K-42040-03 WIRE PLATE 1 300
642 015-00400-70 TAPPING SCREW 2 300
643 33K-41814-08 TAPPING SCREW 2 300
645 33K-42050-11 ROLLING WIRE CP 1 300
647 33K-42080-03 CHOKE BRACKET 1 300
648 011-00600-10 FLANGE BOLT 1 300
660 33K-41833-03 CIRCUIT BREAKER 1 300
665 013-10300-10 SCREW and WASHER AY 2 300
669 33K-41817-03 BREAKER CP 2 300
670 33K-42090-01 TERMINAL BOLT 1 300
671 363-45701-08 TERMINAL BOLT, Red 20A 1 300
672 363-45700-08 TERMINAL BOLT, Blk 20A 1 300
692 33K-41817-13 PANEL HARNESS 1 300
693 33K-41815-01 ENGINE HARNESS 1 300
694 34K-41816-13 DC OUT HARNESS 1 300
710 33K-42060-21 CHOKE WIRE 1 300
767 056-30000-20 WIRE BAND 1 300
780 33K-58411-03 SEAL SPONGE 1 300
902 34K-49511-03 LABEL, front 1 300
903 34K-95101-03 LABEL 2, front 1 300
915 34K-41852-03 FILM INV 1 300
