Subaru RG2800iS 60Hz Silent [19/34] Section 7 intake and exhaust group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

R1700i - 19 - 05-04

SECTION 7 INTAKE and EXHAUST GROUP

10 284-31701-11 CAMSHAFT 1 700

34 227-38601-23 PIN, spring 1

700

35 284-36401-03 RELEASE LEVER 1 700

36 005-19041-00 SPRING PIN 1 700

37 003-15170-00 SNAP RING, outer 1 700

38 274-38701-23 RETURN SPRING 1 700

50 274-33301-03 TAPPET 2 700

60 274-33601-03 VALVE SPRING 2 700

70 274-33702-03 SPRING RETAINER 2 700

80 274-33401-03 INTAKE VALVE 1 700

90 274-33501-03 EXHAUST VALVE 1 700

95 132-10KA0-31 COLLET VALVE 4 700

210 274-35301-03 PUSH ROD 2

700

220 274-36003-03 ROCKER ARM 2 700

230 269-35801-03 BOLT, pivot 2 700

240 017-00600-90 NUT 2 700

260 274-36501-03 GUIDE PLATE 1 700

310 284-30201-20 MUFFLER AY 1 700

315 269-37601-01 SPARK ARRESTOR 1 700

317 015-00400-60 TAPPING SCREW 1 700

340 230-35204-01 GASKET, exhaust 2 700

350 018-00600-30 FLANGE NUT 2 700

365 011-00801-10 FLANGE BOLT 1 700

405 284-34101-03 EXHAUST PIPE 1 700

418 001-14061-60 BOLT and WASHER 2 700

510 284-32630-00 AIR CLEANER 1 700

-2 227-36004-13 PACKING 1 700

520 284-32631-08 ELEMENT 1 700

535 284-32904-01 STAY BAFFLE 1 700

538 277-46701-03 GASKET, choke 1 700

540 284-32903-03 INSULATOR 1 700

550 227-35902-03 GASKET 2, insulator 1 700

560 236-35903-03 GASKET 2, insulator 1 700

570 002-38060-00 FLANGE NUT 2 700

580 011-00601-80 FLANGE BOLT 1 700

750 284-32101-03 DUCT 1 700

850 085-10800-00 RUBBER PIPE 1 700

930 33K-58315-13 SPONGE INSULATOR 1 700

931 33K-58321-13 SPONGE INSULATOR 2 1 700
