Subaru RGX2900 60Hz [11/32] Section 3 intake exhaust group

Subaru RGX2900 60Hz [11/32] Section 3 intake exhaust group

REF PART NO DESCRIPTION QTY REMARKS FROM - TO FIG

RGX2900 - 11 - 08-06

SECTION 3 INTAKE, EXHAUST GROUP

10 278-31601-31 CAMSHAFT 1 300

25 277-35101-03 PIN, camshaft 1 300

27 024-00600-10 O RING 1 300

34 277-38601-03 PIN, spring 1 300

35 277-36401-03 RELEASE LEVER 1 300

37 277-36501-03 CLIP 1 300

38 279-38701-13 RETURN SPRING 1 300

60 279-33601-03 VALVE SPRING 2 300

70 269-33701-03 SPRING RETAINER 2 300

80 277-33401-H3 INTAKE VALVE 1 300

90 277-33501-H3 EXHAUST VALVE 1 300

95 132-10KA0-31 COLLET VALVE 4 300

150 277-35601-11 TIMING CHAIN 1 88 Link 300

160 277-36911-03 TENTIONER 1 300

163 277-37101-03 SPRING, tentioner 1 300

166 277-36902-03 PIN, tentioner 1 300

170 277-36913-13 CHAIN GUIDE 1 300

200 277-35002-01 PIN, rocker 1 300

202 003-13050-00 CLIP 1 300

220 277-36201-00 ROCKER ARM, intake 1 300

225 277-36202-00 ROCKER ARM, exhaust 1 300

230 014-90500-20 ADJUST SCREW 1 300

231 014-90500-20 ADJUST SCREW 1 300

240 017-00500-30 NUT 1 300

241 017-00500-30 NUT 1 300

290 011-00600-20 FLANGE BOLT 1 300

310 277-30202-01 MUFFLER 1 300

315 277-37603-01 SPARK ARRESTOR 1 300

317 015-00400-60 TAPPING SCREW 1 300

320 277-34501-01 MUFFLER COVER 1 1 300

321 277-34601-01 MUFFLER COVER 2 1 300

340 277-35201-13 GASKET, mufﬂ er 1 300

341 277-35201-01 GASKET, exhaust 1 300

350 980-20082-80 FLANGE NUT 2 300

351 980-20082-80 FLANGE NUT 2 300

360 011-00600-20 FLANGE BOLT 3 300

405 277-34001-01 EXHAUST PIPE 1 300

415 010-50802-90 STUD 2 300

540 277-32902-J1 INSULATOR 1 300

550 277-35903-J3 GASKET 2, insulator 1 300

560 277-35902-J3 GASKET 1, insulator 1 300

570 002-38060-00 FLANGE NUT 2 300

580 011-00600-50 FLANGE BOLT 1 300

620 277-39001-01 BRACKET,a/c 1 300

850 277-32762-08 BREATHER PIPE 1 300

855 277-69001-03 SPONGE PROTECTOR 1 300
