Subaru RGX3800 50Hz [7/38] Section 1 crankcase group

RGX3800 - 7 - 07-09

REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.

SECTION 1 CRANKCASE GROUP

10 278-10102-51 Crankcase Cp 1 100

20 237-14202-03 Valve Guide 2 100

26 277-16010-01 Stem Seal 1 100

30 044-02502-00 Oil Seal 1 100

40 060-02800-21 Ball Bearing 1 100

50 277-15011-03 Pipe Knock 2 100

60 010-50802-90 Stud 2 100

70 010-50603-51 Stud 2 100

75 044-00600-20 Oil Seal 1 100

80 040-11400-30 Plug 1 100

90 021-11400-20 Gasket 1 100

210 277-11001-31 Mainbearing Cover Cp 1 100

220 044-02502-10 Oil Seal 1 100

230 X60-02501-40 Ball Bearing 1 100

250 277-45004-J1 Governor Gear Cp 1 100

260 277-41901-03 Governor Sleeve 1 100

270 277-63601-30 Oil Gauge Ay 2 100

280 277-63601-08 Gasket 2 100

300 001-04083-50 Flange Bolt 6 100

610 278-13002-11 Cylinder Head Cp 1 100

620 277-15001-33 Gasket, head 1 100

630 011-00802-40 Flange Bolt 4 100

631 011-00803-10 Flange Bolt 1 100

680 277-15503-01 Rocker Cover Cp 1 100

690 277-16001-13 Gasket, rocker cover 1 100

700 277-15011-03 Pipe Knock 2 100

710 011-00600-20 Flange Bolt 4 100

960 277-99001-47 Gasket Set 1 100
