Subaru RGX5100 60Hz [7/46] Section 1 crankcase group

RGX5100 - 7 - 07-09

REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.

SECTION 1 CRANKCASE GROUP

10 291-10102-51 Crankcase Cp 1 100

20 237-14202-03 Valve Guide 2 100

26 277-16010-01 Stem Seal 1 100

30 044-03001-60 Oil Seal 1 100

40 060-03003-41 Ball Bearing 1 100

50 277-15011-03 Pipe Knock 2 100

60 010-50802-90 Stud 2 100

70 010-50604-10 Stud 2 100

75 044-00600-20 Oil Seal 1 100

80 040-11400-30 Plug 1 100

90 021-11400-20 Gasket 1 100

210 279-11101-21 Main Bearing Cover Cp 1 100

220 044-03001-60 Oil Seal 1 100

230 060-03003-70 Ball Bearing 1 100

250 277-45004-J1 Governor Gear Cp 1 100

260 277-41901-03 Governor Sleeve 1 100

270 279-63601-30 Oil Gauge Ay 2 100

280 279-63601-08 Gasket 2 100

300 001-04083-50 Flange Bolt 7 100

610 279-13002-31 Cylinder Head Cp 1 100

620 279-15001-33 Gasket, head 1 100

630 011-00802-40 Flange Bolt 4 100

631 011-00803-10 Flange Bolt 1 100

680 277-15503-01 Rocker Cover Cp 1 100

690 277-16001-13 Gasket, rocker cover 1 100

700 277-15011-03 Pipe Knock 2 100

710 011-00600-20 Flange Bolt 4 100

960 279-99001-37 Gasket Set 1 100
