Electric air conditioner (split system)

control board do not insert used batteries or batteries of various types.

If the conditioner is not used for a long time, remove batteries from the board or else electrolyte

may leak and damage the board.

In normal operation of the conditioner average service life of batteries will be about a half-year.



does not show a sign of command transfer. When generating commands from the remote con-

trol board, point an IR-radiator at a remote-control signal receiver situated on the indoor unit.

Hold the remote control board at the distance of no more than 8 m from the indoor unit. The re-

mote control board will not work, if there are any curtains, doors or other things between it and

the indoor unit. Protect the board from water and exposure to direct sunlight and heat sources.

7. OPERATING MODES

AUTO mode



board.

During operation in this mode, the air conditioner automatically selects the cooling/heating/fan

mode maintaining the set temperature.

COOL, HEAT and FAN

1. Turn the conditioner on pressing the «ON/OFF button.

2. Pressing the «MODE button, select COOL, HEAT or FAN mode manually.

3. Pressing the «TEMP button (up-down), set the desired air temperature indoors (except for

FAN mode).

4. Pressing the «FAN SPEED button on the remote control board, select the fan rotation speed:

AUTO, LOW, MIDDLE, HIGH, and the conditioner will start working in accordance with the

selected setting.

5. «ON/OFF button once again.

In the FAN mode air temperature indoors is not set.

DRY

Turn the conditioner on pressing the «ON/OFF button. Pressing the “MODE” button, select the



the «ON/OFF button once again.





TIMER mode

Procedure of timing:

1. Press the Timer ON button to activate Timer ON. Each time you press the button you increase

the activation time by 30 minutes ranging from 0 to 10 hours and by 1 hour ranging from 10

to 24 hours. The air conditioner will switch on automatically in the set interval of time.

2. Press the Timer OFF button to activate Timer OFF. Each time you press the button you

increase the activation time by 30 minutes ranging from 0 to 10 hours and by 1 hour ranging


