4. Disassembly and Reassembly
4-1 Compressor Replacement Flow Chart
Samsung Electronics 4-1
Locate cause of defect
Release refrigerant
Disconnect electrical wiring
from compressor
Cut refrigerant lines
from compressor
Plug disconnected lines
Replace compressor
Inspect electrical
wiring for defects,
and terminals for
correct and secure
connections
Solder discharge line
Corrective action
Check refrigerant oil level
Add oil as necessary
Solder suction line Use nitrogen gas
Perform soldering function
Fill system with nitrogen gas
Check for leakage
Recharge system
Recharge system
Evacuate system
Release nitrogen gas?
Problem?
Low oil level?
NY
Y N
N
Y
Leakage?
Содержание
- 1 compressor replacement flow chart 1
- Disassembly and reassembly 1
- Samsung electronics 4 1 1
- 2 1 oil quality 2
- 2 2 replacing and refilling the refrigerant oil 2
- 2 checking the oil 2
- 2 samsung electronics 2
- Fill the transparent container with 10cc of oil and then conduct the test 2
- Replacing the compressor do not fill the system with oil as the compressor is already charged 2 replacing the condenser refill 50cc 3 replacing the evaporator refill 50cc 4 replacing the refrigerant refill 30cc 5 the high pressure side is filled up with oil after the vacuum is completed 6 when the refrigerant leaks it is generally not necessary to refill the oil if the leakage is not severe 2
- 4 disassembly and reassembly procedure 3
- Samsung electronics 4 3 3
- Stop operating the air conditioner and pull out the power cord before repair 3
- 4 samsung electronics 4
- Disassembly and reassembly 4
- No part name procedures remarks 4
- Disassembly and reassembly 5
- No part name procedures remarks 5
- Samsung electronics 4 5 5
