LG V-C3245ND [21/29] How to use

– 20 –

Connecting the flexible hose

Push the end of the head(1) on the flexible

hose(2) into the attachment point on the

vacuum cleaner.

To remove the flexible hose from the

vacuum cleaner, press on the button(3) situ-

ated on the head, then pull upwards.

Assembling the tubes

(depending on model)

• Metal tube(4)

- Fit together the two tubes by twisting

slightly.

•Telescopic tube(5)

- Push spring latch(6) forward.

- Pull out tube to required length.

- Release spring latch to lock.

Using the cleaning head and Accessory

Nozzles

(depending on model)

Fit the large cleaning head onto the end of

the tube.

• The 2 position head(7) is equipped with a

pedal or two pedals(8) which allows you to

alter its position according to the type of

floor to be cleaned.

Hard floor position(tiles, parquet

floors...). Press on the pedal to lower the

brush.

Carpet or rug position. Press on the

pedal to lift the brush up.

• Crevice Tool(9)

For vacuuming in those normally inaccess-

ible places i.e. reaching cobwebs, or down

the side of a sofa!

• Dusting brush(10)

For vacuuming picture frames furniture

outlines, books and other uneven objects.

• Upholstery Nozzle(11)

For vacuuming uphostery, mattresses, etc.

The thread collectors help to pick up the

threads and fluff.

How to plug in and use

Pull out the supply cord to the desired

length and plug into the socket.

Press button (13) to start the vacuum cleaner.

To stop it press the button (13) again.

Adjusting the power level

• If your appliance is equipped with an elec-

tronic variable power control(13), you can

choose the power appropriated for the

task.

(depending on model)

•

The flexible hose handle(14) has a manual

air flow regulator(15) which allows you to

briefly reduce the suction level.

Storage(16)

When you have switched off and unplugged

the appliance, press on the button (12) to

automatically rewind the cord.

You can move or store your appliance in a

vertical position by sliding the hook on the

large cleaning head into the clip on the

underside of the appliance.

How to Use

Changing the dust bag

The dustbag needs changing when the cleaner

is set to maximum power and the cleaner head

is off the floor but the “bag full” indicator win-

dow(17) is completely coloured red.

Even if the dustbag does not appear to be

full at this stage, it should be changed.

It could be that a great deal of very fine dust

has clogged up the pores of the dust bag.

• Turn off the appliance and unplug it.

• Open the cover by pressing the hook(18)

and lifting it up until it snaps into place.

Your appliance is equipped with either a

paper dust bag (19) or a fabric dust bag

(21)(depending on model).

• Take hold of the dust bag by the handle

and pull.Remove the bag and throw it

away.

• To refit a new bag push the cardboard

support of a new bag into the bag mount

(20)until it will go no furthe

If your appliance is fitted with a fab-

ric dust bag follow the same instructions

as above.

Empty it and replace it(21).

Note: as the appliance is fitted with a safety

device which checks that the bag is in place

you cannot close the lid if the bag is not fit-

ted correctly.
