Attaching the stick and the oor nozzle (FC6132 only)

1 To assemble the stick, connect the lower stick part to the upper

stick part (‘click’) (Fig. 2).

Note: You cannot disassemble the stick once you have assembled it.

2 Insert the stick into the attachment point for the stick at the back

of the appliance (‘click’) (Fig. 3).

- Make sure the ridge on the stick aligns with the attachment point on

the appliance when the stick is inserted.

3 To detach the stick from the appliance, press the stick release

button with one hand (1) and pull the stick out of the appliance

with the other hand (2) (Fig. 4).

4 Attachtheoornozzletothenosepiece(Fig.5).

You can use the oor nozzle to clean hard oors and carpets.

The oor nozzle is equipped with a uff collector that removes hair

and uff.

5 Put the plug in the wall socket.

Brush tool and crevice tool

You can use the brush tool to clean delicate surfaces.

With the crevice tool, you can quickly and conveniently clean hard-to-

reach places.

1 Attach the brush tool or the crevice tool to the nosepiece of

the appliance (Fig. 6).

Hose (FC6130 only)

This appliance comes with a hose for extended reach during vacuum

cleaning.

1 Insert the appliance end of the hose into the nosepiece of the

appliance (Fig. 7).

2 Attach the brush tool or the crevice tool to the attachment end of

the hose for extended reach during vacuum cleaning (Fig. 8).
