Philips FC8386 [8/58] English

Motor Protection Filter

Replace the Motor Protection Filter once a year.

If you are using the cotton dustbag, wash the Motor Protection Filter in lukewarm water once a

year.

Make sure the Motor Protection Filter is completely dry before you put it back into the appliance.

1 Switch the appliance off and open the cover.Take out the filter holder and remove the filter

(fig. 19).

2 Insert a new filter into the holder with the white side facing upwards and put the holder

back into the appliance.

Two AFS Micro Filters and one Motor Protection Filter are available under type number FC8032

(883803201010).

Environment

To make recycling possible, the plastics used for this appliance have been coded.

The cardboard packaging has been made of recycled material and is fully recyclable.

Insufficient suction power

1 Check if the dustbag needs to be replaced.

2 Check if the filters need to be replaced.

3 Check if the slide on the handgrip is closed.

4 Check if the electronic suction power control is in maximum position (specific types only).

5 Check if the nozzle, tube or hose is blocked up.To remove the obstruction, disconnect the

blocked-up item and connect it (as far as possible) the other way around. Switch the vacuum

cleaner on to force the air through the blocked-up item in opposite direction (fig. 20).

Guarantee & service

If you need information or if you have a problem, please visit the Philips Web site at

www.philips.com or contact the Philips Customer Care Centre in your country (you will find its

phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your

country, turn to your local Philips dealer or contact the Service Department of Philips Domestic

Appliances and Personal Care BV.

ENGLISH8
