3 / 72 EN
Washing Machine / User’s Manual
2 Installation
RefertothenearestAuthorisedServiceAgentforinstallation
oftheproduct.Tomaketheproductreadyforuse,review
the information in the user manual and make sure that the
electricity,tapwatersupplyandwaterdrainagesystemsare
appropriatebeforecallingtheAuthorizedServiceAgent.If
theyarenot,callaqualifiedtechnicianandplumbertohave
any necessary arrangements carried out.
C
Preparationofthelocationandelectrical,tapwaterand
waste water installations at the place of installation is
undercustomer'sresponsibility.
B
warning: Installationandelectricalconnectionsof
theproductmustbecarriedoutbytheAuthorized
ServiceAgent.Manufacturershallnotbeheldliablefor
damagesthatmayarisefromprocedurescarriedoutby
unauthorizedpersons.
A
warning: Priortoinstallation,visuallycheckiftheproduct
hasanydefectsonit.Ifso,donothaveitinstalled.
Damagedproductscauserisksforyoursafety.
C
Make sure that the water inlet and discharge hoses
aswellasthepowercablearenotfolded,pinchedor
crushed while pushing the product into its place after
installation or cleaning procedures.
2.1 Appropriate installation location
•Placethemachineonarigidfloor.Donotplaceitona
long pile rug or similar surfaces.
•Totalweightofthewashingmachineandthedryer-with
full load- when they are placed on top of each other
reachestoapprox.180kilograms.Placetheproduct
on a solid and flat floor that has sufficient load carrying
capacity!
•Donotplacetheproductonthepowercable.
•Donotinstalltheproductatplaceswheretemperature
mayfallbelow0ºC.
•Placetheproductatleast1cmawayfromtheedgesof
other furniture.
2.2 Removing packaging reinforcement
Tiltthemachinebackwardstoremovethepackaging
reinforcement.Removethepackagingreinforcementby
pullingtheribbon.
2.3 Removing the transportation locks
A
warning: Donotremovethetransportationlocksbefore
taking out the packaging reinforcement.
A
warning: Removethetransportationsafetyboltsbefore
operatingthewashingmachine!Otherwise,theproduct
willbedamaged.
1.Loosenalltheboltswithasuitablespanneruntilthey
rotate freely (C).
2.Removetransportationsafetyboltsbyturningthem
gently.
3.AttachtheplasticcoverssuppliedintheUserManualbag
into the holes on the rear panel. (P)
C
Keepthetransportationsafetyboltsinasafeplaceto
reusewhenthewashingmachineneedstobemoved
again in the future.
C
Never move the product without the transportation safety
boltsproperlyfixedinplace!
2.4 Connecting water supply
C
Thewatersupplypressurerequiredtoruntheproductis
between1to10bars(0.1–1MPa).Itisnecessaryto
have10–80litersofwaterflowingfromthefullyopen
tap in one minute to have your machine run smoothly.
Attachapressurereducingvalveifwaterpressureis
higher.
C
Ifyouaregoingtousethedoublewater-inletproduct
as a single (cold)water-inletunit,youmustinstallthe
suppliedstoppertothehotwatervalvebeforeoperating
theproduct.(Appliesfortheproductssuppliedwitha
blindstoppergroup.)
A
warning: Modelswithasinglewaterinletshouldnotbe
connectedtothehotwatertap.Insuchacasethelaundry
will get damaged or the product will switch to protection
mode and will not operate.
A
warning: Donotuseoldorusedwaterinlethosesonthe
newproduct.Itmaycausestainsonyourlaundry.
1.Connectthespecialhosessuppliedwiththeproductto
the water inlets on the product. Red hose (left) (max. 90
ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is
for cold water inlet.
A
warning: Ensure that the cold and hot water connections
are made correctly when installing the product.
Otherwise,yourlaundrywillcomeouthotattheendof
the washing process and wear out.
2.Tightenallhosenutsbyhand.Neveruseatoolwhen
tightening the nuts.
3. Open the taps completely after making the hose
connection to check for water leaks at the connection
