en
10
Energy saving mode
When the appliance is not used,
the display on the controls switches
to energy saving mode.
■ Energy saving mode display, Fig. "/
6, illuminates.
■ The luminosity of the temperature
displays is reduced.
■ When the “Super” function is switched
on, the corresponding super display is
lit (Super cooling display, Fig. "/2 or
Super freezing display, Fig. "/4).
As soon as you operate the appliance,
e.g. open door or press any button,
the display switches to normal
illumination.
Alarm function
In the following cases an alarm may be
actuated.
Door alarm
The door alarm (continuous sound)
switches on and the “alarm” display "/5
is lit, if the appliance door is open for
longer than one minute. Close the door
or press any button to switch the door
alarm off again.
Temperature alarm
The temperature alarm switches on
if the freezer compartment is too warm
and the frozen food is at risk of thawing.
The temperature display 3 flashes
and the alarm button 5 is lit.
When the alarm button 5 is pressed,
the temperature display 3 indicates for
five seconds the warmest temperature
reached in the freezer compartment.
Then this value is deleted and
the temperature display 3 indicates
the set temperature.
The alarm may switch on without any risk
to the frozen food
■ when the appliance is switched on,
■ when large quantities of fresh food are
placed in the appliance,
■ if the freezer compartment door is
open too long.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Switching off the alarm
Fig. "
Press the alarm button 5 to switch off
the warning signal.
