E
- 12 -
Connecting the flexible hose
Push the end of the head (1) on the flexible
hose (2) into the attachment point on the
vacuum cleaner.
To remove the flexible hose from the vacuum
cleaner, press on the button (3) situated on
the head, then pull upwards.
Assembling the tubes
(depending on model)
• Metal(or Plastic) Pipe (4)
- Fit together the two tubes by twisting
slightly.
• Telescopic tube (5)
- Push spring latch (6) forward.
- Pull out tube to required length.
- Release spring latch to lock.
• Elbow tube (7)
The elbow tube is for uses such as cleaning
under the sofa, table and bed easily.
- Fit the elbow tube onto the end of the
telescopic tube and the grip handle.
- If you pull the latch (8), the elbow tube can
be bent.
- If you stretch the elbow tube, it is returned
to its position.
Using the cleaning head and Accessory
Nozzles (depending on model)
Fit the large cleaning head onto the end of
the tube.
• The 2 position head (9) is equipped with a
pedal (10) which allows you to alter its
position according to the type of floor to be
cleaned.
Hard floor position (tiles, parquet
floors...). Press on the pedal to lower the
brush.
Carpet or rug position. Press on the
pedal to lift the brush up.
• Hard Floor Nozzle (11)
Efficient cleaning of hard floors (wood,
linoleum.etc.)
• Crevice Tool (12)
Flexible Crevice Tool (optional) (13)
For vacuuming in those normally
inaccess-ible places i.e. reaching cobwebs,
or down the side of a sofa!
• Dusting brush (14)
For vacuuming picture frames furniture
outlines, books and other uneven objects.
• Upholstery Nozzle (15)
For vacuuming uphostery, mattresses, etc.
The thread collectors help to pick up the
threads and fluff.
How to plug in and use
Pull out the supply cord to the desired
length and plug into the socket. Tune the
slide knob on the flexible handle from
“OFF” place to the upper place. And then
adjust the power level what you need.
Adjusting the power level
Electronic power control
Slide the knob (16) to desired appropriate
position.
OFF: Power off
Curtain: Lower power
Floor: Full power
Park-System (17)
For short breaks during vacuuming, for
example to move a small piece of furniture
or a rug, use the "Park system" to support
the flexible hose and cleaning head.
Storage (18)
When you have switched off and unplugged
the appliance, press on the button (19) to
automatically rewind the cord.
You can move or store your appliance in a
vertical position by sliding the hook on the
large cleaning head into the clip on the
underside of the appliance.
Changing the dust bag
The dust bag needs changing when the
cleaner is set to maximum power and the
cleaner head is off the floor but the "bag
full" indicator window (20) is completely
coloured red.
Even if the dustbag does not appear to be
full at this stage, it should be changed. It
could be that a great deal of very fine dust
has clogged up the pores of the dust bag.
• Turn off the appliance and unplug it.
• Open the cover by pressing the hook (21)
and lifting it up until it snaps into place.
Your appliance is equipped with either a
paper dust bag (22) or a fabric dust bag
(23) (depending on model).
• Take hold of the dust bag by the handle
and pull.Remove the bag and throw it
away.
• To refit a new bag push the cardboard
support of a new bag into the bag mount
(24) until it will go no further.
• Before you replace the full dust bag, you
should hold the bag mount and lift it after
opening the filter cover (25).
