E
How to Use
Connecting the flexible hose
To remove the flexible hose from the vacuum
cleaner, press the button (3) situated on the
head, then pull upwards.
Assembling the tubes
(depending on model)
• Plastic or metal tube (4).
- Fit together the two tubes by twisting slightly.
- Cleaning turbine brush nozzle
- Fit the elbow tube onto the end of the telescopic
tube and the grip handle.
- If you pull the latch (30), the elbow tube can
be bent.
- If you stretch the elbow tube, it is returned to
its position.
• Telescopic tube (5)
- Push spring latch (6) forward.
- Pull out tube to required length.
- Release spring latch to lock.
Using the cleaning head and Accessory
Nozzles (depending on model)
The 2- position head (7) is equipped with a
pedal (8) which allows you to alter its position
according to the type of floor to be cleaned.
•
Hard floor position (tiles, parquet floors...).
Press on the pedal to lower the brush.
Carpet or rug position. Press on the pedal
to lift the brush up.
•
Fit the large cleaning head onto the end of
the tube.
•
Hard Floor Nozzle (31)
Efficient cleaning of hard floors (wood,
linoleum,etc.)
Press the button on the rear side of the
nozzle to separate the air cover.
Use the dusting brush & crevice tool to
vacuum clean the brush and fan.
•
•
Turbine brush nozzle (32)
•
Elbow tube (29)
The elbow tube is for uses such as cleaning
under the sofa, table and bed easily.
Crevice Tool (9)
For vacuuming in those normally inaccessible
places i.e. reaching cobwebs, or down the
side of a sofa!
•
Dusting brush (10)
For vacuuming picture frames, furniture
outlines, books and other uneven objects.
•
Upholstery Nozzle (11)
For vacuuming uphostery,mattresses,etc.
How to plug in and use
Pull out the supply cord to the desired length
and plug into the socket.
Press button (12) to start the vacuum cleaner.
To stop it press the button (12) again.
The thread collectors help to pick up the
threads and fluff.
Adjusting the power level
Park-System (17)
Electronic power control (27)
MIN: Low power
MAX: Full power
For short breaks during vacuuming, for
example to move a small piece of furniture
or a rug, use the "Park system" to support
the flexible hose and cleaning head.
Even if the dustbag does not appear to be
full at this stage. it should be changed, as
very fine dust can clog up the pores of the
dust bag.
Storage (18)
Changing the dust bag
When you have swiched off and unplugged
the appliance, press the button (13) to
automatically rewind the cord.
You can move or store your appliance in a
vertical positin by sliding the hook on the
underside of the appliance.
The dustbag needs changing when the
cleaner is set to maximum power and the
cleaner head window (19) is completely
coloured red.
Turn off the appliance and unplug it.
Open the cover by pressing the hook (20)
and lifting it up until it snaps into place.
At first, push the dust cover (37) upwards, the
dust cover fixes. Then push the end of the
head (1) on the flexible hose (2) into the
attachment point on the vacuum cleaner.
Turn off the appliance and unplug it.
Open the cover by pressing the hook (20)
and lifting it up until it snaps into place.
- 20 -
