14
Operation
Press and hold SEEK- /SEEK+
buttons on the RC or on the panel to start
automatic seeking for an available TV channels
downward or upward. After being found the
channel will be played. To stop seeking, press
one of these buttons again.
Auto memory store/select channels
• Press P.SCN/RPT button on the RC to
automatically search all available channels in the
current frequency range. The detected channels
will be automatically stored in the memory. To
stop preset scan, press the button again.
• To select saved channels press number
buttons on the RC. Or press SEEK-
/
SEEK+
buttons on the panel, and then
rotate VOLUME knob.
Disc/USB/SD/MMC operations
USB/SD/MMC notes
USB format supports 2.0. Capacity: up to
32 Gb. For correct and satisfactory operation,
licensed SD/MMC memory cards of famous
brands should be used with this unit. Avoid
using memory cards of unknown brands.
Capacity: up to 32 Gb. FAT/FAT32 file systems
are supported.
The output capacity of the USB
socket does not exceed 500 mA (according
to the standard requirement to this socket).
Connecting USB drives with power
consumption exceeding this value as well as
defective USB drives may cause mechanical
or thermal changes of elements of this unit as
well as failure of internal elements of the USB
port. Such damages are not warrantee cases.
Warning: usage of external USB drives
containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.
Insert/Eject disc
• Open the front panel and insert a disc into
the disc slot with label side up. The disc will be
automatically loaded into the unit. The first file
in the root folder will be played. Close the front
panel.
• Open the front panel and press EJECT
button to eject the disc from the slot. If the disc
is not removed from the slot within several
seconds, it will be automatically loaded into
the slot again. When the disc is ejected and
removed, the unit will automatically switch to
another mode.
Inserting an SD/MMC card/USB device
Open the front panel and insert an SD/
MMC memory card into the card slot. Open the
USB slot cover on the front panel and insert
a USB into the USB slot. Then the playing
mode will be changed into Card or USB mode
automatically. The first card/USB device track
playback will start.
When SD/MMC card and USB device are
both inserted, the playing mode will be changed
into the mode of the device inserted later.
Play/pause
The unit will automatically play from the first
sound track recorded on a disc/SD/MMC/USB
device. To ensure good system performance,
wait until the unit finishes reading the disc/
device information before proceeding. Press
button on the RC or MEM button on the
panel to pause playback, press it again to
resume playback.
MP3/DivX/JPEG file playback
When you insert a storage containing MP3/
DivX/JPEG file, the screen will show following
interface:
