3
INSTALLATION (continued)
To Connect External Equipment
The following are diagrams showing basic instructions for attaching external equipment, like a VCR or DVD
player, to your TV set. Please refer to operation manuals of external audio/video equipment that will be
connected to your set for additional instructions. PLEASE TURN OFF ALL POWER BEFORE CONNECTING
DEVICES TOGETHER.
Notes:
1. Do turn off the power supply of the TV set and the external equipment before connection.
2. The side terminals may be easier to use with a camcorder. The connections are identical.
3. DVD IN and AV IN terminals share the same AUDIO IN terminals.
4. The side˄front˅AV and rear AV are parallel. Do not use the side (front) AV and real AV at the same
time.
Coaxial Cable
Connect VCR s RF OUT terminal to the RF IN jack I cated on the rear'o
Connect VCR s RF OUT terminal to the RF IN jack I cated on the rear'o
PF IN
VCR
DVD Piayer
YCbCr
Cr Cb
Y
VIDEO
AUDIO
A V IN
Audio Cable
Video Cable
Camcorder
VCR
Audio Cable
Video Cable
DVD IN
ANTENNA IN
ANTENNA IN
AV IN on the side panel
AV IN on the side panel
L
R
R
R
AUDIO
AUDIO
VIDEO
VIDEO
AV IN
AV
OUT
AV
OUT
L
L
