Elenberg MS-2003M [20/22] Countertop installation

INSTALLATION

Turntable Installation

a. Never place the glass tray upside

down. The glass tray should never be

restricted.

b. Both glass tray and turntable ring

assembly must always be used during

cooking.

c. All food and containers of food are

always placed on the glass tray for

cooking.

d. If glass tray or turntable ring as-

sembly cracks or breaks, contact your

nearest authorized service center.

Countertop Installation

Remove all packing material and accessories. Examine the oven for

any damage such as dents or broken door. Do not install if oven is

damaged.

Cabinet: Remove any protective ﬁlm found on the microwave oven

cabinet surface. Do not remove the light brown Mica cover that is

attached to the oven cavity to protect the magnetron.

INSTALLATION

1. Select a level surface that provide enough open space for the

intake and/or outlet vents.

A minimum clearance of 7.5cm

is required between the oven and

any adjacent walls. One side must

be open.

(1) Leave a minimum clearance of

30cm above the oven.

(2) Do not remove the legs from

the bottom of the oven.

(3) Blocking the intake and/or

outlet openings can damage the

oven.

(4) Place the oven as far away from radios and TV as possible.

Operation of microwave oven may cause interference to your radio

or TV reception.

2. Plug your oven into a standard household outlet. Be sure the

voltage and the frequency is the same as the voltage and the fre-

quency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-

producing appliance. If installed near or over a heat source, the

oven could be damaged and the warranty would be void.
