DF140A E01 013 - 1 -
PREFACE
When it becomes necessary to replace parts on SUZUKI OUTBOARD MOTORS, always
use SUZUKI GENUINE PARTS which have passed a strict inspection which guarantees
quality and performance.
This parts catalogue covers the list of all service parts for SUZUKI DF140A
production start 2012.
INSTRUCTIONS FOR QUOTING THE CATALOGUE
1. DIMENSIONS
Dimensions of the parts in this catalogue are indicated in unit millimeters.
2. ABBREVIATIONS
Abbreviations used in this catalogue are as follows:
AR : As required NT : Number of teeth
ASSY : Assembly OPT : Optional
E.NO. : Engine number OS : Over size
F.NO. : Frame number STD : Standard
D : Diameter of material T : Thickness
ID : Inside diameter US : Under size
OD : Outside diameter W : Width
L : Length W/ : With
LH(PORT) : Left hand side S,L,X,LL : Transom type
RH(STBD) : Right hand side SUS : Stainless steel
～123456 : Up to E.NO.14002F-123456 PTT : Power trim and tilt
123456～ : From E.NO.14002F-123456
12 x 34 x 5.6
........
Figures in the description column
| | | show the dimensions of parts.
ID OD T(or W,L)
→12345-56781 (Parts No.) : indicates that the parts number was
changed to 12345-56781 and the new parts are interchangeable with
the former ones but the former ones are not interchangeable with
new ones.
←12345-56781 (Parts No.)
: indicates that the former and new
parts are interchangeable with each other and both are usable.
DF140A E01 013 - 2 -
3. INNER PARTS OF ASSEMBLY
Part name with a dot (.) in front as shown in the description column indicates
the component of the assembly also available individually.
4. MODIFICATION NOTICE
A parts bulletin will be sent to you on all occasions when changes in parts
occur, including interchangeable modifications between new parts and old ones.
5. NOTE
5-1. There are some different parts from those of production models among
spare parts for the administrative reasons and common use of them with
other models.
5-2. In respect of rubber hoses and vinyl tubes, please be sure to use them
by cutting off according to the length mentioned on parts catalogue or
what is actually required on the vehicle.
5-3. Note that the drawings on the illustration page are for ready reference
of spare parts number, not to be used as an assembly manual.
When assembling, use "SUZUKI SERVICE MANUAL".
6. MODEL NAME AND ENGINE NUMBER
MODEL DESTINATION TYPE TRANSOM ENGINE No.
DF140AT E01,E40 14002F L,X 14003F-310001～
DF140AZ E01,E40 14002Z L,X 14003Z-310001～
