Pioneer MVH-150UBG [3/32] English

Black plate (3,1)

Indicator State

Main infor-

mation sec-

tion

! Tuner: band and fre-

quency

! RDS: program service

name, PTY information

and other literal informa-

tion

! USB storage device:

elapsed playback time

and text information

Appears when a lower tier of

folder or menu exists.

Set up menu

When you turn the ignition switch to ON after in-

stallation, set up menu appears on the display.

You can set up the menu options below.

1 After installation of this unit, turn the

ignition switch to ON.

SET UP appears.

2 Turn M.C. to switch to YES.

# If you do not operate for 30 seconds, the set up

menu will not be displayed.

# If you prefer not to set up at this time, turn M.C.

to switch to NO. Press to select.

If you select NO, you cannot set up in the set up

menu.

3 Press M.C. to select.

4 Perform the following procedures to set

the menu.

To proceed to the next menu option, you need to

confirm your selection.

LANGUAGE (multi-language)

This unit can display the text information from a

compressed audio file even for information em-

bedded in English or Russian.

! If the embedded language and the selected

language setting are not the same, text infor-

mation may not display properly.

! Some characters may not be displayed prop-

erly.

1 Turn M.C. to select the desired setting.

ENG (English)—РУС (Russian)

2 Press M.C. to confirm the selection.

CLOCK SET (setting the clock)

1 Turn M.C. to adjust hour.

2 Press M.C. to select minute.

3 Turn M.C. to adjust minute.

4 Press M.C. to confirm the selection.

FM STEP (FM tuning step)

Normally, the FM tuning step employed by seek

tuning is 50 kHz. When AF or TA is on, the tuning

step automatically changes to 100 kHz. It may be

preferable to set the tuning step to 50 kHz when

AF is on.

! The tuning step remains at 50 kHz during man-

ual tuning.

1 Turn M.C. to select the FM tuning step.

50 (50 kHz)—100 (100 kHz)

2 Press M.C. to confirm the selection.

QUIT appears.

5 To finish your settings, turn M.C. to select

YES.

# If you prefer to change your setting again, turn

M.C. to switch to NO. Press to select.

6 Press M.C. to select.

Notes

! You can set up the menu options from the

system menu. For details about the settings,

refer to System menu on page 7.

! You can cancel set up menu by pressing

SRC/OFF.

Basic operations

Important

! Handle gently when removing or attaching

the front panel.

! Avoid subjecting the front panel to excessive

shock.

! Keep the front panel out of direct sunlight

and high temperatures.

! To avoid damaging the device or vehicle inte-

rior, remove any cables and devices attached

to the front panel before detaching it.

Removing the front panel to protect your unit from

theft

1 Press the detach button to release the front

panel.

2 Push the front panel upward (M) and then pull

it toward (N) you.

3 Always keep the detached front panel in a pro-

tection device such as a protection case.

Re-attaching the front panel

1 Slide the front panel to the left.

Make sure to insert the tabs on the left side of

the head unit into the slots on the front panel.

2 Press the right side of the front panel until it is

firmly seated.

If you cannot attach the front panel to the

head unit successfully, make sure that you are

placing the front panel onto the head unit cor-

rectly. Forcing the front panel into place may

result in damage to the front panel or head

unit.

Turning the unit on

1 Press SRC/OFF to turn the unit on.

Turning the unit off

1 Press and hold SRC/OFF until the unit turns

off.

English

Operating this unit

Section

Operating this unit

<QRB3391-A>3

Pioneer MVH-150UBG [3/32] English
