2
5. Service drawings
5.1 Wheel assembly and throttle cable service drawing
23
5.2 Water tank and grip service drawing
24
4. Mounting the cut-off saw
4.1 Opening the clamp
1615
1.Open the grip clamp .
2.Release the saw support axle clamp and slide it upwards.
4.2 Bringing the saw into position
1817
1.Engage the saw support axle in the saw mount, as shown.
2.Position the grip of the saw on the grip clamp.
4.3 Securing the saw
2019
1.Close the grip clamp and tighten the screw to secure the grip .
2.Close the saw support axle clamp and tighten the clamping screw .
4.4 Fitting and adjusting the throttle cable
2221
1.Fit the throttle lever and secure it in position.
2.Adjust the throttle cable until free from play and then tighten the locknut.
2.4 Fitting the grip
87
1.Fit the grip using the clamping screw and washer.
2.Tighten the clamping screw securely.
2.5 Fitting the water tank
109
1.Pivot the tank support upwards and then tighten the clamping screw
securely.
2.Position the tank on the support and push it downwards until it engages.
3. Fitting the water supply
3.1 Fitting the water nozzle
1211
1.Fit the water nozzle .
2.Fit the hose clip .
3.2 Fitting the hose
1413
1.Tighten the hose clip .
2.Use a cable tie to secure the hose .
TT-C walk-behind saw trolley
1. Safety precautions
● Use this walk-behind saw trolley only with Emak cut-off saws of the type 963TT-
A - 983TT-A - TT163 - TT 183 - HS 63 - HS 81A.
● Observe the instructions and safety precautions listed in the operating instruc-
tions for your Emak cut-off saw.
2. Assembling the walk-behind saw trolley
2.1 Fitting the wheels
21
1.Fit the wheel , washers and split pins onto the wheel axle .
2.Expand the split pins .
2.2 Fitting the axle and wheel
43
1.Fit the axle and tighten the clamping screws.
2.Fit the second wheel (see 2.1).
2.3 Fitting the cutting depth adjustment arm
65
1.Fit the cutting depth adjustment arm ) using the clamping lever
with washer and the mounting screw with washer and lockwasher.
2.Tighten the mounting screw and clamping lever .
TT-c impag 52030099A.qxd 16-11-2005 16:35 Pagina 2
