General information

Wi-Fi

frequency, MHz 2400 - 2483.5

power, mWt 40

protocol 802.11 b/g/n

Bluetooth 4.0

frequency, MHz 2400 - 2483.5

power, mWt 10

protocol 802.15.4

3G WCDMA frequency, MHz 2100

GSM GSM-900 GSM-1800 GSM-1900

MS transmission/BTS reception freq.,

MHz 890-915 1710-1785 1850-1910

MS reception/BTS transmission freq.,

MHz 935-960 1805-1880 1930-1990

Connectors and terminals microUSB, microSD slot, earphone

output, 2 x SIM-3G card slots

GPS +

FM-radio +

Power Li-ion battery 2000 mAh

Battery operation time up to 240 hours in idle mode/

up to 4 hours in talking mode

Operation temperature range +5

- +40

Storage temperature range -20

- +60

Specifications are subject to change without notice. Dimensions are

approximate.

This device is equipped with a capacitive-type screen panel. When

operating the device do not exert significant pressure (exceeding 500 g) on the

screen to prevent its damage. If excessive pressure is applied, interferential

leakages and fringes may appear on the screen. This is a visual reaction to

excessive pressure of a multilayered structure of the screen and is not a warranty

case.

Areas with non-uniform backlite on the edges of the screen are normal,

this is a sctructural feature of the LCD-screen and is not a warranty case.

The LCD-screen of the smartphone is a high-technology device,

containing a great number of thin-film transistors which give a clear, finely detailed

picture. Sometimes inactive dots of various colors (blue, green, red, black or

white) may appear on the screen. This is not a defect and does not affect the

characteristics of your device.
