Telefunken TF-MID1007G [17/37] Table of contents
![Telefunken TF-MID1007G [17/37] Table of contents](/views2/1097470/page17/bg11.png)
Table of contents
Specifications
Unit dimensions/Net weight 173 х 9.9 х 263 mm/0.64 kg
CPU Quad core MTK8389 Cortex A7; 1.2 GHz
Operating system Android 4.2 Jelly Bean
Display 10.1” capacitive IPS, 5-point multi touch
Screen resolution 1280x800 pixels
GPU Power VR SGX 544MP2, Open GL 2.0
Main camera 5 MP (auto focus)
Front camera 0.3 MP
Supported audio formats MP3, WMA, WAV, APE, FLAC, AAC, OGG
Supported video formats AVI, MP4, RM, RMVB, FLV, MOV, 3GP
Supported photo formats JPEG, BMP, GIF, PNG
Supported text formats PDF, TXT, EPub
Memory built-in flash 16 GB + slot for microSD card up
to 32 GB
RAM DDR III, 1 GB
Wi-Fi specifications
frequency, MHz 2400-2483,5
power, mWt 40
protocol 802.11 b/g/n
Bluetooth 4.0 AES
frequency, MHz 2400-2483,5
power, mWt 10
protocol 802.15,4
3G WCDMA frequency, MHz 2100
Connectors and terminals micro HDMI, microUSB, microSD slot,
earphone output, SIM-3G card slot
GPS +
Power battery 7000 mAh (3.7 V)
Battery operation time up to 6 hours of HD video playback
Operation temperature range +5
0
- +40
0
Storage temperature range -5
0
- +50
0
Specifications are subject to change without notice. Dimensions are approximate.
This device is equipped with a capacitive-type screen panel. When operating the
device do not exert significant pressure (exceeding 500 g) on the screen to prevent its damage. If
excessive pressure is applied, interferential leakages and fringes may appear on the screen. This
is a visual reaction to excessive pressure of a multilayered structure of the screen and is not a
warranty case.
Areas with non-uniform backlite on the edges of the screen are normal, this is a
sctructural feature of the LCD-screen and is not a warranty case.
The LCD-screen of the tablet PC is a high-technology device, containing a great
number of thin-film transistors which give a clear, finely detailed picture. Sometimes inactive dots
of various colors (blue, green, red, black or white)may appear on the screen. This is not a defect
and does not affect the characteristics of your device.
17
Содержание
- Dear customer 2
- Table of contents 2
- Before you start 3
- Connectors 3
- General provisions 3
- Health and safety of the user 3
- Important safeguards 3
- Power adapter ports and 3
- Battery 4
- Before you start 4
- Cleaning and maintenance 4
- Utilization of the product 4
- Control elements 5
- Front panel 5
- Operation 5
- Rear panel 5
- General operation 6
- Operation 6
- Power on off 6
- Rebooting the device 6
- Status bar 6
- The main screen 6
- Adding removing objects on the 7
- Desktop 7
- Operation 7
- Upgrading basic software os 7
- Wallpaper 7
- Call forwarding 8
- Making calls 8
- Operation 8
- Connecting external usb devices 9
- Connecting to wi fi 9
- Connections 9
- G connectivity 9
- Operation 9
- Applications 10
- Connecting memory cards 10
- Connecting to pc 10
- Hdmi out 10
- Installing applications 10
- Operation 10
- Deleting applications 11
- List of applications 11
- Operation 11
- Operation 12
- General information 13
- System setup 13
- The device menu 13
- The personal menu 13
- The settings menu 13
- The wireless networks menu 13
- General information 14
- The accounts menu 14
- The system menu 14
- General information 15
- Troubleshooting guide 15
- Accessories 16
- General information 16
- Warranty 16
- Specifications 17
- Table of contents 17
- Содержание 18
- Уважаемый покупатель 18
- Адаптер питания разъемы и порты 19
- Здоровье и безопасность 19
- Меры предосторожности 19
- Общие положения 19
- Перед началом эксплуатации 19
- Пользователя 19
- Аккумуляторная батарея 20
- Жидкокристаллический дисплей 20
- Перед началом эксплуатации 20
- Чистка и уход 20
- Перед началом эксплуатации 21
- Утилизация изделия 21
- Задняя панель 22
- Передняя панель 22
- Управление устройством 22
- Элементы управления 22
- Включение выключение 23
- Главный экран 23
- Основные операции 23
- Перезагрузка устройства 23
- Управление устройством 23
- Добавление удаление объектов 24
- Рабочего стола 24
- Строка состояния 24
- Управление устройством 24
- Обновление базового 25
- Обои рабочего стола 25
- Осуществление звонков 25
- Программного обеспечения os 25
- Управление устройством 25
- Переадресация вызовов 26
- Подключение 3g 26
- Подключение по wi fi 26
- Подключения 26
- Управление устройством 26
- Накопителей 27
- Подключение внешних usb 27
- Подсоединение карты памяти 27
- Управление устройством 27
- Hdmi выход 28
- Накопителя 28
- Подключение в режиме usb 28
- Приложения 28
- Управление устройством 28
- Установка приложений 28
- Список приложений 29
- Удаление приложений 29
- Управление устройством 29
- Управление устройством 30
- Меню беспроводные сети 31
- Меню настроек 31
- Меню устройство 31
- Настройка системы 31
- Общая информация 31
- Меню аккаунты 32
- Меню личные данные 32
- Меню система 32
- Общая информация 32
- Общая информация 33
- Общая информация 34
- Руководство по устранению неисправностей 34
- Общая информация 35
- Гарантийные обязательства 36
- Комплект поставки 36
- Общая информация 36
- Технические характеристики 36
- Общая информация 37
