Telefunken TF-MID9705RG [8/35] Operation
![Telefunken TF-MID9705RG [8/35] Operation](/views2/1097485/page8/bg8.png)
Operation
8
Operation
and operating system (OS) updates (if any)
on the manufacturer’s website. Do not use
the OS updates for other models, as they are
incompatible and cannot provide full and stable
operation of the device.
• If your device is working properly do not
update the software, as it is quite possible that
the device has a newer version of the software
installed.
• Before upgrading/replacing the OS make
sure that the OS is designed for models with
the same serial numbers as your device (the
serial number is located on the back panel
of your device). To perform the upgrade/
replacement of the OS, follow the instructions
posted on the page of this model on the
manufacturer’s website.
Connections
Connecting to Wi-Fi
• Click the applications menu button (4) in
the top right corner of the main screen, in the
APPS tab select “Settings”. In the WIRELESS
& NETWORKS section click Wi-Fi to set it into
the ON position.
• Connecting to the network: The system
automatically detects available Wi-Fi-networks
and displays their names; select a network you
want to connect to and, if necessary, enter the
password. When the connection is established,
the display shows the Wi-Fi icon (11) in the
notification area. The number of blue sectors in
the icon shows the strength of the Wi-Fi signal.
To add a Wi-Fi network to the list, click
“Add Network” in the top right corner, then use
the pop-up keypad to enter the network name
and click “Save”.
After disabling Wi-Fi please switch the
3G module off and on again.
3G connectivity
Insert a 3G SIM-card into the appropriate
slot on the unit. Click the applications menu
button (4) in the top right corner of the main
screen, in the APPS tab select “Settings”. In
WIRELESS & NETWORKS select “More ...”
Click on “Mobile networks”, put a tick next to
«Modem power» and enter the PIN-code. In
the “Mobile network settings”, select “Access
Point». Select your access point from the
list or adjust manually. When a successful
connection is performed, icon appears in
the system tray.
Once the SIM-card is inserted and
initialized, you must reboot the device to
ensure the correct network registration and
functionality.
• When using a device with 3G, while
out of network coverage, you must disable
the transmission of data in order to stop the
system from constantly trying to register in the
network. This is recommended to prevent poor
system performance and a shorter battery life.
• Impossibility of a 3G-connection can
be caused by a lack of 3G coverage in your
location, and in this case it is not a defect of
the device.
A-GPS
• The A-GPS function enables you to
determine the coordinates of the location of
mobile devices and display it on the map. The
positioning is performed via cellular connection
channel and/or Wi-Fi.
• Click the applications menu button (4)
in the top right corner of the main screen, in
the APPS tab select “Settings”. In “Location
services” put a tick next to the option “Google’s
location service” and remove the tick for the
option “GPS satellites». Now when you start
working with map application (Google Maps),
after clicking on the icon the map will
display the location of your device.
Connecting external USB-devices
• Connect an external USB-drive with a
microUSB cable to the microUSB or USB
(OTG-host) port of this unit. Run the “Explorer”
application and select “USB” to access the
contents of the connected drive.
• You can connect other peripheral USB-
8
