CS1822 / CS4824 RS-232 Commands

Audio Mixer

The Audio Mixer command allows you to enable / disable the CS1822 /

CS1824’s audio mixer function. The default setting is off.

Use the Formula - to set Parameters - to create a Command.

Formulas:

Command + Control + [Enter]

Parameters:

Note: The audio port number for xx cannot be identical to yy.

Audio Mixer Command

The available formula for the Audio Mixer command is as follows:

1. Command + Control + [Enter]

For example, to enable the CS1822 / CS1824’s audio mixer for audio port 01

and audio port 02, type the following:

audio ron 01 02 on [Enter]

Command Description

audio Audio Mixer Command

Control Description

off Disable audio mixer (Default)

ron xx yy Select two audio ports for audio mixer

xx, yy= 01, 02 (CS1822) / 01, 02, 03, 04 (CS1824)

pon xx Select a permanent audio port for audio mixer

xx= 01, 02 (CS1822) / 01, 02, 03, 04 (CS1824)

on Enable audio mixer

Enter Description

Enter Enter and send out command
