Chapter 4. OSD Operation
61
After entering the information, click Save.
Enable Media Select which type of media the receiver can stream from
transmitters: video, audio, USB, and RS-232.
Manager
Address
Set the IP address and Port number of the PC running the KVM
over IP Matrix Manager. The default port number is 9110.
Beeper Check this box to allow the receiver to sound a beep when
configuration changes are made to it.
Touch Screen
Calibration
Use this button to calibrate the surface of a USB touch screen
connected to the unit. When the calibration screen appears,
touch the flashing
+
symbol at the corners until the process is
complete.
USB Mode Select the type of USB device connected to the USB ports:
Virtual Media: Only select this option if you are plugging a USB
disk into the USB ports. This will give you the highest data
transfer speeds but will not allow other USB devices plugged
into the USB ports to work. When receivers connected to the
same transmitter mount or unmount USB disk drives, the
keyboard and mouse operations will experience a brief delay.
Transmitters can support up to 12 virtual media connections at
the same time (keyboard/mouse included).
vUSB (Generic USB device): Use this option to plug USB
peripherals* into the USB ports. This option also allows a
keyboard and mouse with special functions to plug into the USB
ports for console use. Use this only if the special functions of the
keyboard or mouse are required but do not work when plugged
into the console ports. When the keyboard and mouse are
plugged into the USB ports, they will not work within the OSD
menus. To work within the OSD menus, the keyboard and
mouse must be plugged into the console ports. In this mode,
RCMDVI00AT / RCMDVI40AT / RCMDVI00BT / RCMDVI40BT /
RCMDVI50T transmitters supports up to 5 USB connections.
Encryption: Check this box to encrypt USB drives plugged into
the USB ports.
Receiver
Keyboard
Use the Keyboard Country Code drop-down menu to select the
receiver’s language keyboard for use in the OSD.
Disable front
video button
You can enable or disable the function (select video mode or
graphic mode) of the video pushbutton on the front of the
receiver.
Check Disable to disable.
Uncheck Disable to enable.
Item Description
