Chapter 1. Introduction
3
Requirement
Console
A VGA monitor
A USB mouse
A USB keyboard
Components
KA7171 Front View
No. Component Description
1 PC Port Plug the appropriate connectors on the USB-
PS/2 KVM cables set to a local computer.
2 Remote LED Lights green to indicate that the local console
access is active.
3 Local LED Lights green to indicate that the KA7171 link to
the KVM switch is active. Flashing indicates
that the KVM switch is sending/receiving data
to/from the console.
4 Operating Mode
Selection
Pushbutton
Push to select between Remote / Local
modes.
1
2
3
4
