Aten CS231TK [10/36] Features

Chapter 1. Introduction

Features

 Single computer shared by two USB consoles

 Supports Access Control Box which allows users to prohibit Console 2

from controlling (operating) (CS231TK only)

 Supports USB and PS/2 computers

 Multiplatform support (Windows, Mac, Unix, and Linux)

 Manual or Auto console selection

 Control the system with Hotkeys

 Firmware upgradable

 Private Mode for a privileged user

 Screen Saver function

 Choose from four Timeout settings

 Supports VGA, SVGA, and MultiSync monitors

 No software required
