Руководство пользователя Страница: 24

Aten VE8952T [24/122] Ve8900t ve8950t ve8952t top view

VE8900 / VE8950 / VE8952 User Manual

VE8900T / VE8950T / VE8952T Top View

No. Component Function

1ID display

panel

An ID display that identifies its ID number.

2 prev (+) / next

(-) buttons



Assign ID numbers on VE8900 / VE8950 devices.



Assign the source video (transmitter) for the receiver.

3 link LED Lights orange to indicate the LAN port 1 is connected to an

Ethernet switch. For information, see Status LEDs, page 21.

4 power LED Lights green to indicate the unit is receiving power. For

information, see Status LEDs, page 21.

3 4

1 2
