VE814A User Manual
3
Planning the Installation
Requirements
Prepare the following before installing the VE814A unit:
Considerations
Note that the maximum transmission distance varies at different parts of the
transmission depending on the transmission interface:
Note: The maximum transmission distance using a Cat 5e/6/6a or
an ATEN 2L-2910 cable can go up to 150 m when long reach mode is
enabled.
Required Equipment Details
Display device
1 HDMI display capable of the highest required
resolution.
Source device
1 source device with an HDMI port.
Cables
1 Cat 5e/6/6a cable for connecting the VE814AT and
VE814AR.
Note: For best video quality, we strongly recommend
using the ATEN 2L-2910 Cat 6 cable to connect the
VE814AT and VE814AR.
Connection Interface Distance
Computer to the VE814AT HDMI 1.8 m
VE814AT to VE814AR Cat 5e/6/6a
2L-2910
100 m*
VE814AR to the display HDMI 5 m
