UH3238 User Manual
2
Getting Started Tasks
The UH3238 USB-C Travel Dock is a portable device that helps you expand
your USB-C workstation without having to connect USB mouse, USB
keyboard, monitor, external hard drive, and a headphone set. Connecting the
USB-C and other peripheral devices to the UH3238 USB-C Travel Dock
allows you to access all peripherals, while providing power delivery to the
connected USB devices.
Recommended Procedure
Follow the steps below to get started with your UH3238 USB-C Travel Dock.
Step Task Detailed Information
1 Unpack the package and check if you have
the following items:
1 x UH3238 USB-C Travel Dock with
Power Pass-Through
1 x user instructions
2 Check if your mobile device or computer is
supported by the UH3238 USB-C Travel
Dock.
See Supported Host Devices and
Requirements, page 3.
3 Prepare the following equipment:
1 x UH3238 USB-C Travel Dock
1 x USB-C PD power adapter of at least
65W (not included in the package)
Note: Please use the original power
adapter from the iPad Pro package. For
laptop charging, a pure USB-C PD
(LPS-certified) of at least 65 W power
adapter is recommended.
1 x USB-C enabled host device
1 x HDMI enabled monitor
1 x USB keyboard
1 x USB mouse
1 x headphone set
4 Connect your prepared devices. See Connecting the Unit, page 7.
See Troubleshooting, page 14.
