- 9 -

Installation

To set up the UH3233, use the diagram on the next page (the

numbers in the diagram correspond with the numbered

instructions below), and do the following:

1. Use the USB-C to USB-C cable (included with the package)

to connect the laptop's USB-C port to the UH3233.

Note: 1. To ensure a good connection, check that the Power

LED on the top of the UH3233 is on.

2. When the LED on the top of the UH3233 lights

orange, please connect an AC adapter to the USB

device connected to the USB 3.1 Gen 1 Type-C port,

as the orange light indicates that the connected

laptop cannot provide enough power for the USB-C

device.

2. Connect a USB device (keyboard/mouse/peripheral/adapter)

to the USB 3.1 Gen 1 Type-A port on the UH3233.

3. Connect an HDMI cable from the monitor to the HDMI Port 1

on the UH3233.

4. Connect a second HDMI cable from the monitor to the HDMI

Port 2 on the UH3233.

5. Power on the laptop and monitors.

1. Make sure that the power to any device that you

connect to the installation has been turned off.

2. Make sure that all devices you will be installing are

properly grounded.
