3. On the UDP Client Server of PC1, you can enter any text to test if it can be received by PC2, as

exemplified below.

Note: Conversely, you can also enter any text on the Putty of PC2 to test if it can be received by the UDP

Client Server of PC1.

D. Appendix

ATEN Secure Device Server Pin Assignment

Configuration

RS-232

RS-422/RS-485 (4-wire)

RS-485 (2-wire)

DCD

RxD- (A)

RxD

RxD+ (B)

TxD

TxD+ (B)

Data+ (B)

DTR

TxD- (A)

Data- (A)

GND

DSR

RTS

CTS
