2. Description

The gun for the abrasion of ejector type. It is supposed for dry abrasive jet cleaning of the surfaces

with limited compressed air input and at low work volume. The tool is ideal for abrasive jet works in

the tighten conditions and in the cases the use of pressure abrasive jet tool is not possible for some

reasons.

The gun may operate with any abrasives (silica sand, fused alumina) for these operations; it can be

also used for metal and stone cleaning, glass decorative finish.

The gun is equipped with the connecting pipes to connect with the pneumatic line and the tube for

abrasive input. The structure of the receiving nozzle allows abrasive receiving both from rigid

package and envelope (model 110116). The gun (model 110115) is equipped with its own abrasive

tank. The cleaning process starts after pressing the start lever of the gun.

Operation principle of the gun: exhaustion is created in the vessel behind the air nozzle.As the result

of it abrasive intake through the tube of the tank takes place. The abrasive gets into the vessel

through the corresponding connecting pipe, then is mixed with the main airflow and taken out

through the nozzle.At directing the air and abrasive tongue cleaning takes place.

Caution:

If revealing any faults immediately discontinue the operation.

When connecting the pneumatic tool to the compressor hose always block the air escape

cock.

Always follow the safety rules when using the compressed air.

3s. Technical pecifications

The manufacturer reserves himself the right to make the manual's content or function

change without any preliminary notification of the users.

tools

MODEL 110115 110116

Nozzle diameter, mm 6,0 10,0

Inlet diameter, inch 1/4 1/4

Operating pressure air consumption, l/min 142 138

Operating pressure, bar 3,5 3,0

Abrasive consumption, gr/min 200 200

Tank capacity, ml 750 -

Weight, kg 0,5 0,33
