1
English
2
Technical Information
Amplifier
Total Power: 7 Watt RMS
Power distribution: 3.5 Watt x 2
Harmonic distortion: < 1 % 1 W 1 kHz
Frequency response: 80 Hz - 20 kHz
Signal/Noise ratio: > 75 dB
Separation: > 45 dB
Speakers
Tweeter driver type: 1”
Tweeter impedance: 4 Ohm
Mid-range speaker type: 3”
Mid-range speaker impedance: 4 Ohm
Interfaces
Output: 3.5 mm stereo jack for headphones
Input: 3.5 mm stereo jack for auxiliary audio input, 3.5 mm stereo plug
Frequently Asked Questions (FAQ)
Questions Answers
Check of the audio source is working well.
Check if the audio and speaker cables are well connected.
Ensure volume is correctly adjusted
What are the products
supported?
If the problem still exists, please contact the distributor or ask for professional service
Check if the volume is at lower level and the Mp3
format is recorded at above 196 bitrate
Check the 3.5mm jack and plug for proper connection
and cable is firmly inserted
Intermittent sound
No Sound
Sound is distorted
© 2013 Microlab Electronics Co., Ltd All rights reserved.
- The end -
EN
6
Any playback devices such as PC, notebook, CD/DVD player
with stereo sound outputs, Media Players with 3.5mm
stereo jack or plug.
Static sound heard when volume
knob is turned
Turn off the playback source first, then turn the speaker
volume knob several times. Playback again and monitor.
What are these speakers ideal
for?
Bookshelf speakers are ideal for most multimedia
applications with full-range sound reproduction capabilities
Built with full-range drivers, it is efficient
in handling sound from movies, music, games and CD.
80-B57-97-3154-01 2013-01-30 (Russian manual)
80-B57(BA)-97-0001-01 2013-03-14 (English for Russian cust)
80-B58(13)-97-0001-01 2013-09-12 (English for Woxter cust / Microlab version)
