Microlab H21BT [3/4] Features

Introduction

or when the apparatus is left unused for a long period of time.

19. Servicing - Do not attempt to service this product yourself, as opening or removing covers may expose you

to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

20. Please remove the power plug form the main power source or wall power source when not in use. When

plugged in to a power source, the system is in standby mode, so the power is not entirely cut off.

21. Replacement parts - When replacement parts are required, ensure the service technician has used

replacement parts specified by the manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

22. Mains fuses - For continued protection against fire hazard, use fuses only of the correct type and rating.

The correct fuse specification for each voltage range is marked on the product.

23. Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you

do, the speaker may be damaged when a peak level section is suddenly played.

24. The only means of completely disconnecting the product from the power supply is by removing the power

cord from the wall outlet or the product. The wall outlet or the power cord entry to the product must remain

freely accessible at all times while the product is in use.

25. Try to install the product near a wall socket or extension cord and shall be easily accessible.

26. The highest environmental temperature suitable for this product is 40°C.

Incorporating Bluetooth® technology for wireless music entertainment. This system lets you connect

to your mobile phone or media player without cables. Using A2DP or AVRCP profiles, it lets you listen

to stereo music by connecting to any Bluetooth® enabled device.

Designed with beautiful leather finishes, this versatile stereo system fits perfectly in your living room,

computer room or even your bedroom. Bass reflex tunnel design means deeper bass effects. Classic

bookshelf stereo speaker arrangement creates better dynamic sound movements for realistic effects.

Ideal for digital movies, TV. PC / notebooks, CD / DVD and multimedia application.

Comes with two audio input methods, wireless Bluetooth® music transfer and traditional audio

connection. Features advanced non-contact connection using NFC technology with any NFC enabled

product.

Features

Wireless Bluetooth® music entertainment; playback from any Bluetooth® devices

Bookshelf stereo speakers for all room types such as living room, kitchen, bedroom, etc.

Bluetooth® A2DP profile supported for wireless music streaming

Bluetooth® AVRCP profile supported for mobile phone remote control

Powerful and clear sound with built-in amplifier

Treble and bass sound effects

Full range sound spectrum for all type of accurate music reproduction

Support alternative analog 3.5 mm stereo connection to traditional media players

High fidelity terminal binding posts for clearer sound and minimum noise

Package contents

H21 speakers 2 pcs

Speaker interconnect cable 1 pc

AC/DC power adapter 1 pc

3.5 mm stereo to 2RCA cable 1 pc

User manual 1 pc

Function Instruction

Connections

Rear Views

Mp3 / Mp4

Media player

PC or Notebook

Media

player

CD / DVD

Blu-Ray player

To AC

power source

To 3.5mm stereo

playback source

Right speaker

Left speaker

Interconnect

cable

USB charging

output

2RCA audio

input

Terminal

Binding post

Bass

Reflex

Port

Front Views

sou rce

volu me

Right speaker

Left speaker

Top panel

Bluetooth mode

LED

Line IN mode

LED

Standby mode

/ Source selector

Bluetooth

pairing LED

Pair / Play / Pause

Previous track

Next track

Master volume

dial

NFC zone

1. Turn on the main AC power and Power switch. The system will initiate standby mode with no LED

illumination

2. Depress the button with the Standby icon to activate the Source selection mode. The default mode

is Bluetooth® wireless. You can depress again to select between Bluetooth® or LINE IN modes.

3. Depress the same button for several seconds and the system will return to Standby mode.

4. In Bluetooth® mode, if no pairing occurs for 20 minutes, the Standby mode will be activated.

5. In LINE IN mode, if no pairing occurs for 20 minutes, the Standby mode will be activated.

6. Depress the SOURCE button once to initiate the Bluetooth® wireless mode. (For previously

paired device, the system will remember its last volume level setting)

7. The Bluetooth® LED lit up in blue, and the pairing sequence initiates after 10 seconds with

Bluetooth® Sync LED blink between red and blue colours rapidly. The Bluetooth® mode is

the default source selection.

8. Immediately pair and connect with your Bluetooth® music device. Once paired, the

Bluetooth® LED will remain lit steadily. (Skip this step if “H21” remembered your device).

9. To activate the pairing sequence anytime, depress the Pair/Play/Pause button for 3 seconds or

more. The pairing sequence will commence and search for any Bluetooth enabled device.

10. This product supports NFC connection method, please refer to the NFC paragraph for more

information.

NFC

Illustrations

DC input

Bluetooth

Wireless

connection

Smartphone

Notebook

Tablet

80-H21-97-0001-01 2011-10-18

80-H21(ERP2)-97-0001-01 2013-01-05

80-H21(DA)-97-0001-01 2013-11-15 (ERP2 / NFC version)

80-H21(DA)-97-0001-01 2014-04-25 (for LiYun)

80-H21(DA)-97-0001-02 2014-05-29 (Change Paired LED to steady / for LiYun)
