REMOTE WIRELESS CLOUD CARD
RWCCARD100
REMOTE WIRELESS CLOUD CARD
RWCCARD100
Copyright © 2021 Cyber Power Systems, Inc. All rights reserved.
2
31
INSTALLATION GUIDE
NOTE: The Remote Wireless Cloud Card is
hot-swappable, so you do not need to turn o the
device to install it.
NOTE: You can reset the Remote Wireless Cloud
Card back to its factory settings by pressing and
holding the Reset button. It will begin to flash blue
once it’s reset.
3. Insert and tighten the retaining screws.
4. Please ensure the LED Status is flashing blue.
2. Install the Remote Wireless Cloud Card
into the expansion slot.
1. Remove the two retaining screws from
the expansion slot, and remove the cover.
Step 1. Hardware Installation
Definitions for the LED Indicators
LED Status (Color)
Blue
(Flashing)
Green
(Flashing)
Green
Condition
The Remote Wireless Cloud Card is not connected
to the Router.
The Remote Wireless Cloud Card is being
connected to the Network.
The Remote Wireless Cloud Card is connected to
the Network.
Step 2. Application Installation
Install the “POWERPANEL” application available for download on the
Apple App Store or Google Play, then launch the application.
Figure 1
Step 3. Sign Up and Login, as shown in Figure 1
Step 4. Add a device in the POWERPANEL app
1. Click “+” in the upper right corner of the homepage, as shown in Figure 2.
Figure 2
iOS Android
Quick Start Guide
STATUS
RESET
Power
RWCCARD100
Cloud
Reset Button
Network Indicator
2. Select “Add Device by WiFi” to add your Remote Wireless Cloud Card.
3. Connect the Remote Wireless Cloud Card you are installing.
- Go to your phone's Settings > Wi-Fi
- Make sure the Wi-Fi is turned on, and choose the network, like the example
below, to connect to the wireless card
- Enter the default password: cyberpower
- Once connected, return to the application
NOTE: If you were not prompted to turn on your phone's location, verify it’s
on now.
4. If the Remote Wireless Cloud Card is connected, then you will see “Setting
WiFi” on the bottom of the page.
5. Select and connect to your Wi-Fi router and name the device you are
monitoring.
