Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 6
1.4 I/O Panel 8
Chapter 2 Installation 10
2.1 Installing the CPU 11
2.2 Installing the CPU Fan and Heatsink 14
2.3 Installing Memory Modules (DIMM) 15
2.4 Expansion Slots (PCI Express Slots) 17
2.5 Jumpers Setup 18
2.6 Onboard Headers and Connectors 19
2.7 CrossFireX
TM
and Quad CrossFireX
TM
Operation Guide 24
2.7.1 Installing Two CrossFireX
TM
-Ready Graphics Cards 24
2.7.2 Driver Installation and Setup 26
2.8 M.2 WiFi/BT Module Installation Guide 27
2.9 M.2_SSD (NGFF) Module Installation Guide (M2_1) 29
2.10 M.2_SSD (NGFF) Module Installation Guide (M2_2) 32
Chapter 3 Software and Utilities Operation 36
3.1 Installing Drivers 36
3.2 A-Tuning 37
3.3 ASRock Live Update & APP Shop 40
