English
6
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
CPU VCORE, CPU VDDCR_SOC, DRAM, VPPM, PREM
VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage
Multi-adjustment
Hardware
Monitor
•
Temperature Sensing: CPU, CPU/Water Pump, Chassis,
Chassis/Water Pump Fans
•
Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/
Water Pump Fans
•
Quiet Fan (Auto adjust chassis fan speed by CPU tempera-
ture): CPU, CPU/Water Pump, Chassis, Chassis/Water
Pump Fans
•
Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis,
Chassis/Water Pump Fans
•
Voltage monitoring: Voltage monitoring: +12V, +5V, +3.3V,
CPU Vcore, CPU VDDCR_SOC, DRAM, PREM VDDCR_
SOC, +1.8V, VDDP
OS
•
Microso® Windows® 10 64-bit
Certica-
tions
•
FCC, CE
•
ErP/EuP ready (ErP/EuP ready power supply is required)
Please realize that there is a certain risk involved with overclocking, including
adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using
third-party overclocking tools. Overclocking may aect your system’s stability, or
even cause damage to the components and devices of your system. It should be done
at your own risk and expense. We are not responsible for possible damage caused by
overclocking.
* For detailed product information, please visit our website:
http://www.asrock.com
