- 4 -
GA-B250-FinTech Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-B250-FinTech motherboard 5 I/O Shield
5 Motherboard driver disk 5 3-in-1 PSU Power-On Adapter
5 User's Manual 5 Front Panel Switch Card
5 Two SATA cables
KB_MS_USB
CPU_FAN
SYS_FAN1
LGA1151
ATX
GA-B250-FinTech
F_AUDIO
AUDIO
BAT
ATX_12V_2X4
Intel
®
B250
USB30_LAN
CODEC
CLR_CMOS
BIOS
D_SUB
PCIEX16
PCIEX1_6
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1F_USB2
F_PANEL
SATA3
1 0
3 2
COM
F_USB30
R_USB30
SYS_FAN2
DDR4_1
DDR4_2
DVI
DDR4_3
DDR4_4
CPU DRAM
VGA BOOT
SATA3 5 4
SYS_FAN3
SPDIF_O
PCIE_12V_2
PCIE_12V_1
PCIEX1_5
PCIEX1_11
PCIEX1_4 PCIEX1_10
PCIEX1_3 PCIEX1_9
PCIEX1_2
PCIEX1_8
PCIEX1_1
PCIEX1_7
