ROG CROSSHAIR VII HERO specifications summary
Storage
AMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation
Processors
- M.2_1 Socket 3 with M Key, type 2242/2260/2280/22110 (PCIE
3.0 x4 and SATA modes) storage devices support
- M.2_2 Socket 3 with M Key, type 2242/2260/2280 (PCIE 3.0 x4)
storage devices support
AMD Ryzen™ with Radeon™ Vega Graphics Processors*
- M.2_1 Socket 3 with M Key, type 2242/2260/2280/22110 (PCIE
3.0 x4 and SATA modes) storage devices support
AMD 7th Generation A-series/Athlon™ Processors*
- M.2_1 Socket 3 with M Key, type 2242/2260/2280/22110 (SATA
mode) storage devices support
AMD X470 chipset
- 6 x SATA 6Gb/s ports
* M.2_2 will be disabled for these processors.
Audio
ROG SupremeFX S1220 8-Channel high-definition CODEC
- Supports up to 32-Bit/192kHz playback*
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input
- Impedance sense for front and rear headphone outputs
- ES9023P High Denition DAC
- SupremeFX Shielding Technology
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Feature:
- Sonic Studio III
- Sonic Radar III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-channel audio.
LAN
Intel
®
Ethernet Controller I211-AT
Anti-surge LANGuard
ROG GameFirst IV
