en Note The O ring only prevents loss of the feather key during transport and is not used any further 3 Push a 0 19 x 42 washer 3c onto the axle 4 Insert the lock washer 3b into the shaft groove in front of the washer and press it into the groove until it engages 5 Press the cover cap 3a onto the hub 6 Pull the rear of the tractor in the direction of the other rear wheel until you can hear it make contact with the rim 7 Remove the factory fitted rubber O ring 8 Push a 0 19 x 42 washer 3c onto the axle 9 Insert the lock washer 3b into the shaft groove in front of the washer and press it into the groove until it engages 10 Press the cover cap 3a onto the hub MOUNTING THE STEERING WHEEL 1 Set the front wheels to the to the strai ght ahead position 2 Place the clamping sleeve 4a on the stee ring column 3 Place the steering wheel 4b on the clamping sleeve Note Make sure the position is correct with the spoke pointing towards the operator 4 Insert the washer 4c and the cup spring 4d 5 Fasten the steering wheel 4b using the he xagon bolt 4e Make sure the tightening torgue is 20 Nm Use a torgue wrench 6 Put on the cover 4f MOUNTING THE OPERATOR S SEAT 1 Remove the shaft fastener 5a from the seat 5c 2 Pull out the shaft 5b 3 Pass the shaft back into the seat 5c and re install the shaft fastener 5a 4 Connect the seat contact switch 6a 5 Attach the cable 6b of the contact switch 6a to the lug 5d using cable ties Mounting the steering wheel HOOKING IN THE FILL LEVEL SIGNAL TRANSMITTER OF THE GRASS CATCHER Hooking in the fill level sensor of the grass catcher The fill level sensor uses a horn to signal when the grass catcher must be emptied The grass catcher must be removed in order for the fill level sensor to be fitted 1 Push the fill level sensor 26a into the opening in the rear wall Make sure the fill le vel sensor is in the correct position 2 Push it into the opening straight and without excessive force until you can feel it engage ASSEMBLING GRASS CATCHERS Use a battery operated screwdriver with a Torx bit TX30 for assembly 1 Insert the support plate in the bottom part of the grass catcher on both sides 7 2 Guide in horizontally and swivel upwards 8 9 and 10 3 Clamp the front support strut 11a into the lower part of the grass catcher 11b and use M6x35 carriage bolts washers and self lo cking nuts to screw on from the outside 12 4 Screw the top part of the frame 13a firmly onto the support strut using M6x35 carriage bolts washers and self locking nuts 5 Connect the top part to the support plates and screw on using 2 Torx Tx30 and four carriage bolts 14 and 15 6 Trap the fabric of the grass catcher in the top part 16 7 Put on the grass catcher cover and screw it onto the frame 18 and 19 Note Oval head screw Torx M6x22 and wa sher 0 6x18 8 Insert the hand lever through the grass cat cher 20 secure the oval head screw Torx M6x35 and self locking nut to prevent them being pulled out 21 INSTALLING THE STARTER BATTERY MOUNTING THE CRUISE CONTROL LEVER 1 Mount the control lever 25a for the cruise control using an M5 x 20 Allen key and a wa sher 12 The lawn tractor is supplied with a starter battery The starter battery mount is located under the en gine cover The starter battery is always supplied from the factory pre charged 476148_a
