ASUS TUF B360M-PLUS GAMING
1-1
Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
TUF B360M-PLUS GAMING
PCIEX16
PCIEX1_1
PCIEX1_2
CLRTC
SPDIF_OUT
AAFP
EATXPWR
CHA_FAN1
CPU_FAN
CHA_FAN2
BATTERY
Super
I/O
ALC
887
DIGI
+VRM
24.4cm(9.6in)
LGA1151
Intel
®
B360
Intel
®
1219-V
DDR4 DIMM_B1 (64bit, 288-pin module)
2280 2260 2242
2280 2260 2242
M.2_2(SOCKET3)
M.2_1(SOCKET3)
DDR4 DIMM_B2* (64bit,288-pin module)
DDR4 DIMM_A1 (64bit, 288-pin module)
DDR4 DIMM_A2* (64bit, 288-pin module)
AUDIO
KBMS_USB78
HDMI
LAN_U31G2_12
U31G1_C3
23.1cm(9.1in)
128Mb
BIOS
SATA6G_6 SATA6G_5
SATA6G_4 SATA6G_3
SATA6G_2 SATA6G_1
U31G1_56
PANEL
USB1011
RGB_HEADER
USB914
COM
PCIE
SATA
M.2_1(SOCKET3)
IRST
X4 V
X
PCIE
SATA
M.2_2(SOCKET3)
IRST
X4 V
X
DVI
EATX12V
321 41
1
8910
7
6
2
121314
16
11
17
16
15
1
5
ScantheQRcodetogetthedetailedpindenitions.
