8 How to install your monitor hardware
4. Route the cables via the loose bracket.
Release the cable retaining clip by squeezing the clip
inwards as illustrated. Position the cables together and
reinsert the clip over them to retain the cables neatly in
place behind the monitor stand.
5. Connect-to and turn-on the power.
Plug the other end of the power cord into a power point
and turn it on.
Turn on the monitor by pressing the power button on the
front of the monitor.
Turn on the computer too, and follow the instructions in
Section 4:
Getting the most from your BenQ monitor to install
the monitor software.
