2 3
Instruction manual Instruction manual
Important safeguards
• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.
• Do not hit or drop the unit.
• Do not expose the unit to vibration,
direct sunlight, too high or low temperature or
humidity.
• If you are not going to use the unit within
a long period of time, remove the batteries to
avoid their leakage.
• Do not disassemble the unit yourselves.
Refer servicing to qualified service personnel.
Power supply
Battery operation
• Insert 1 x 9 V battery 6F22 type (not
included) to the terminal inside the battery
compartment. The set will not work normally
from the battery supply, but there is now
the advantage that, in case there is a mains
current failure, your clock will continue to work.
The clock display will not light up, the clock
time will be held in the clock memory by the
battery back-up system. This enables you to
move the set from place to place without re-
setting the clock every time. The battery back-
up system is only meant to be used from short
temporary power failures. For longer durations
the battery may become exhausted or there
may be some deviation in accuracy.
• When the battery is exhausted, it should
be removed from the set to prevent leakage.
If you do not wish to take advantage of the
battery back-up system, your set will work
normally without a battery. However, if
disconnected from the mains, the clock figures
will flash when the mains are re-connected and
you must re-set the clock.
AС operation
• The appliance is for household use only.
• Before the first connecting of the appliance
check that voltage indicated on the rating label
corresponds the mains voltage in your home.
• Insert the plug into the power supply.
• The set is now working as an electronic
clock. Figures will blink on the display, showing
that you should set the clock.
Setting the clock
• Press and hold TIME button.
• Do not release TIME button; press HOUR
button or MIN button to set the clock display to
the correct time.
• Release all the buttons when finished the
setting.
Radio operation
Tuner operations
• Slide ON/OFF/AUTO switch to ON position
to turn on the radio.
• Slide USB/FM/AM switch to AM or FM
position.
• Adjust the frequency by using TUNING
regulator.
• Use VOLUME regulator to adjust volume
level.
• To obtain better FM signal reception,
extend the FM wire antenna to its full length.
• This unit is equipped with a built-in ferrite
antenna. Select the best orientation of this unit
to get a better reception of AM signal.
• To turn off the radio set ON/OFF/AUTO
switch to OFF position.
Sleep to music
The radio or USB (if a USB device is
connected) can be set to play and to switch off
automatically after a preset time.
• Slide USB/FM/AM switch to a position to
select USB or radio band to play.
