5 When charging is completed, the indicator lights green.

Remove the battery pack or the transceiver from the

charging slot of the charger.

• It takes approximately 3 hours to charge the battery pack.

• When the charger will not be used for a long time, unplug the

AC adapter from the AC outlet.

Note:

◆ When the indicator blinks red, the battery pack is either defective or

the battery pack contacts are not properly mated with those of the

charger.

◆ When the indicator flashes green and orange, the battery pack

has not satisfied the charging start temperature. Remove the

battery pack from the charger and wait until it reaches a normal

temperature before charging it again.

◆ The ambient temperature should be between 41°F and 104°F (5°C

and 40°C) while charging is in progress. Charging outside this range

may not fully charge the battery.

◆ The battery pack life is over when its operating time decreases even

though it is fully and correctly charged. Replace the battery pack.

INSTALLING THE CAP OVER THE SPEAKER/

MICROPHONE JACKS

Install the cap over the speaker/ microphone jacks when not

using an optional speaker/ microphone.

Note: To keep the transceiver water resistant, you must cover the

speaker/ microphone jacks with the supplied cap.

1 Place the cap over the jacks so that the locking tabs

insert into the transceiver grooves.

2 While holding the cap in place, push it towards the

bottom of the transceiver until the tabs on the cap click

into place.

• To remove the cap, hold the top of the cap in place

with your finger while inserting a

2 mm or smaller flat blade screwdriver under the

bottom of the cap. Slowly slide the screwdriver

in until its tip touches the tab inside the cap, then

gently pry the cap up (handle of screwdriver moving

away from the transceiver) to remove the cap.
