PRESIDENT ELECTRONICS PRESIDENT PM-500 SWF [7/28] Attaching the beltclip

Connect Drop-In Charger with AC adaptor

Plug one end of the AC adaptor into the wall outlet and

the other end into the drop-in charger.

The drop-in charger is not water proof. En-

sure the radio is dry before connecting to

the charger.

Don’t use the charger when the ambient

temperature is below 0º C (32º F) or above

45º C (113º F).

Install the Battery Pack

Your radio uses the supplied NiMH battery pack.

To install the NiMH battery pack:

1. Make sure the radio is off.

2. Turn the screw holding the battery compartment counterclockwise with a

screwdriver, and hold up the battery cover.

3. Put the NiMH battery pack in the battery compartment applying the battery

contacts to the lower charge contacts. Be sure to follow the instructions

written on the battery pack’s label. Installing the battery pack incorrectly will

prevent the unit from operating.

4. Before placing the battery cover back on the radio, check the rubber seal

around the battery compartment and the ribbon of the battery pack: make

sure that the seal is in good condition and that there is no foreign matter

under the seal.

5. Replace the battery compartment door. Tighten the screws securely.

If the rubber seal appears warn, nicked, or dried out, replace-

ment seals are available.

Use only the supplied NiMH battery pack. Do not charge alkaline

or non rechargeable batteries.

Attaching the Beltclip

To attach the belt clip:

Slide the belt clip until it snaps into place.

To remove the belt clip:

To remove the belt clip, press and hold belt clip locker, slide the belt clip at the

same time until released.
