VOICE SYSTEMS BEE-Stage [22/44] Technical specs
![VOICE SYSTEMS BEE-Stage [22/44] Technical specs](/views2/1989526/page22/bg16.png)
BEE Series – Compact Professional Speaker System
22
Technical specs
BEE LIVE
BEE MAX
BEE STUDIO
BEE
THEATRE
(Tone burst
10%/20ms)
W IHF 90 W (90+30) W
(90+30) W
passive version 150W
DISTORSION (THD+N) < 0.1%
Input
Impedance
Kohms
30 (balanced line) -15 (unbal line)
2 (balanced mic) - 1 (unbal mic)
Input
Sensitivity
DB
0 (0.775 V) Line
-30 dB Mic
Power supply See label on the apparatus
Sensitivity
(SPL 1W/1m)
DB 89 91 91
Frequency
Response
Hz (-10dB) 80-16000
70-20000 (Bee Max)
65-20000 (Bee Studio)
70-20000
DISPERSION (OxV) ° 60 x 60 90 x 60
MAX SPL DB 109 112
COMPONENTS 1x5" full range
5” Woofer
+ 0,8”compression
tweeter
2x4” Woofers
+ 1” compression
tweeter
CONSTRUCTION Composite molded, high impact enclosure.
CONTROLS Hi Definition, Line level, Mic level, GND Lift .
CONNECTIONS
Mic input: 1 XLR -F, Line input: 1 XLR -F
Mix out, Link: 1 x Jack
DIMENSIONS mm (LxHxD) 182 x 330 x 226 182 x 330 x 226 182 x 330 x 226
WEIGHT Kg 4,2 4,4(Max –4,6(Studio) 4,5
