![Sennheiser XSW 1-825 DUAL-B [3/78] System](/views2/1989623/page3/bg3.png)
XS WIRELESS 1 | 1
ENFRITPTNLPLSEDKFI
GR
RUZH ES
DE
KO
COMPLIANCE
Technische Daten
Modulationsart Breitband-FM
Frequenzbereiche A: 548 bis 572 MHz
GB: 606 bis 630 MHz
B: 614 bis 638 MHz
BC: 670 bis 694 MHz
C: 766 bis 790 MHz
D: 794 bis 806 MHz
E: 821 bis 832 MHz und 863 bis 865 MHz
K: 925 bis 937,5 MHz
Schaltbandbreite Bis zu 24 MHz
Frequenzen 8 Kanalbänke mit jeweils bis zu 10 voreingestellten
Kanälen
Signal-Rausch-Abstand ≥ 103 dBA
Klirrfaktor ≤ 0,9 %
Temperaturbereich im Betrieb: 0 °C bis +40 °C
Lagerung: –20 °C bis +70 °C
Sender-Synchronisation 2,4 GHz, RF Power <3 mW, Low Power OQPSK
(nur während Synchro nisation aktiv)
System
EM-XSW1 EM-XSW1 DUAL
Empfängerprinzip Double-Superheterodyn
Diversity Prinzip Antenna Switching Diversity über interne Antennen
Empfindlichkeit (bei Spitzenhub) < 3 μV bei 52 dB(A)
eff
S/N
Audio-Übertragungsbereich 50 bis 16 000 Hz ( –3 dB)
max. Audio-Ausgangsspannung
(bei Spitzenhub, 1 kHz NF)
6,3-mm-Klinkenbuchse (unsymmetrisch): +6 dBu
XLR-Buchse (symmetrisch): +12 dBu
Audio-Einstellbereich 45 dB, einstellbar in 5-dB-Schritten
Spannungsversorgung
12 V ⎓ nom. / 300 mA 12 V ⎓ nom. / 500 mA
Rauschsperre (Squelch) Einstellbar von 3 dBμV bis 28 dBμV
(kombiniert mit Pilotton)
Line-/Mic-Pegel 20 dB umschaltbar
Gehäusematerial robustes ABS-Gehäuse
Abmessungen (B x H x T) ca. 200 x 42 x 127 mm ca. 320 x 42 x 127 mm
Gewicht ca. 340 g ca. 610 g
Empfänger
